Product features:
- Line length 100MM
- Connector IPEX 1
- RF1.13
- Gain 30dbi
| Product performance | |
|---|---|
| Model | WT-A-28*28-100MM-IPex1 |
| Frequency range | 1561-1575.42MHZ |
| Atanding wave ratio | ＜1.8 |
| Antenna gain | 30dBi |
| Impedance | 50Ω |
| Connector type | Welding IPEX 1 generation |
| Type | GPS+BD dual frequency L1+L5 built-in active antenna |
| Wire length | 100mm |
| Wire rod | RF1.13 |
| Size | 28mm*28mm*10mm(+/-0.5mm) |
| Voltage | 3V-5V |
| Power Consume | 50W |
| Humidity range | 5% to 95% non-condensing |
| Working Temperature | -40℃ to +85℃ |
| Storage Temperature | -40℃ to +85℃ |
